305” LUMINA 960 Outdoor LED Billboard Display – P4mm Video Wall Bundle – W22.05’ x H12.60’ (6.72m x 3.84m) Outdoor Fixed and Rental LED Screen for Business Advertising – Wireless Remote Content Control

Description

Engineered for demanding outdoor environments, the LED Display 960 Outdoor P4 delivers exceptional brightness, weatherproof reliability, and rugged mechanical precision. Housed in a robust die‑cast aluminum enclosure with a 960×960×146 mm (37.80″×37.80″×5.74″) footprint, it combines IP65 protection with flexible mounting wall‑mount, ground‑support, overhead hanging, or billboard rail—to suit permanent façades, billboard installations, rental staging, jumbotron applications, and outdoor fixed setups.

Whether deployed as a long‑term outdoor video wall, stadium jumbotron, sports‑venue perimeter screen, rental show façade, or roadside billboard, the LED Display 960 Outdoor P4 pairs ultra‑high brightness, weatherproof durability, and easy serviceability to excel in the most challenging conditions.

The P4mm outdoor led panel features a 960mm x 960mm x 146 mm die‑cast aluminum cabinet machined to ± 0.3 % tolerance, housing a 240 x 240 pixel array of SMD 1921 LEDs on a 2‑layer, 1.6 mm PCB. CFD325 driver ICs run a 1/10 scan at 7,680 Hz with 15‑bit gray‑scale depth for artifact‑free video and text, while a Nova A5s Plus receiving card ingests data via direct Ethernet. Triple Nandian NDB300PS5 power supplies deliver up to 750 W peak, driving clear 6000 nits of brightness (cd/m²) at ≥ 5000 : 1 contrast and a 12,000 K white point across a 160°

x 160° viewing angle. Full‑front and full‑back access simplify servicing, making it suitable for wall mounting, ground‑support, hanging, billboard, truss, or jumbotron frames, and the IP65‑rated, non‑coated surface resists water, dust, and debris. Weighing 31 kg (68 lbs) and powered by AC 100–240 V, 50/60 Hz, it’s built to withstand the rigors of permanent outdoor installation.
